Information
- Paper topic: Rendering
- Software type: Code
- Able to run a replicability test: False
- Replicability score: 5
- License: unspecified
- Build mechanism: CMakeLists, Not applicable (python, Matlab..)
- Dependencies: umfpack / sparseqr/ libvips / jupyter
- Documentation score {0,1,2}: 1
- Reviewer: Julie Digne
Source code information
Comments
Linux : compiled successfully after several major changes:
** File mitsuba-layers/src/liblayer/microfacet.cpp: because of a delete use of = for a std::bind, I changed lines 602 forward to:
auto const &integ1 = std::bind(µfacet_fresnel, mu_o, mu_i, 0.0, std::placeholders::_1, alpha_u, alpha_v, eta_);
auto const &integ2 = std::bind(µfacet_fresnel_no_additional_factors, mu_o, mu_i, 0.0, std::placeholders::_1, alpha_u, alpha_v, eta_);
auto integrand = &integ1;
if (fresnel_only) { integrand = &integ2; }
** File mitsuba-layers/include/mitsuba/layer/sparse.h add #include<memory>
** File mitsuba-layers/ext/enoki/include/enoki/alloc.h add #include<cstring>
** File mitsuba-layers/CMakeLists.txt : add -fpermissive to CMAKE_CXX_FLAGS
** Files mitsuba-layers/ext/openexr/CMakeLists.txt an nori/ext/openexr/CMakeLists.txt
add_custom_target(CopyIlmBaseLibs
COMMAND ${CMAKE_COMMAND} -E copy_directory
${CMAKE_CURRENT_BINARY_DIR}/IlmBase/Half/
${CMAKE_CURRENT_BINARY_DIR}/OpenEXR/IlmImf/
COMMAND ${CMAKE_COMMAND} -E copy_directory
${CMAKE_CURRENT_BINARY_DIR}/IlmBase/IlmThread/
${CMAKE_CURRENT_BINARY_DIR}/OpenEXR/IlmImf/
COMMAND ${CMAKE_COMMAND} -E copy_directory
${CMAKE_CURRENT_BINARY_DIR}/IlmBase/Iex/
${CMAKE_CURRENT_BINARY_DIR}/OpenEXR/IlmImf/
COMMAND ${CMAKE_COMMAND} -E copy_directory
${CMAKE_CURRENT_BINARY_DIR}/IlmBase/Imath/
${CMAKE_CURRENT_BINARY_DIR}/OpenEXR/IlmImf/
)
instead of
add_custom_target(CopyIlmBaseLibs
COMMAND ${CMAKE_COMMAND} -E copy_directory
${CMAKE_CURRENT_BINARY_DIR}/IlmBase/Half/$<CONFIGURATION>
${CMAKE_CURRENT_BINARY_DIR}/OpenEXR/IlmImf/$<CONFIGURATION>
COMMAND ${CMAKE_COMMAND} -E copy_directory
${CMAKE_CURRENT_BINARY_DIR}/IlmBase/IlmThread/$<CONFIGURATION>
${CMAKE_CURRENT_BINARY_DIR}/OpenEXR/IlmImf/$<CONFIGURATION>
COMMAND ${CMAKE_COMMAND} -E copy_directory
${CMAKE_CURRENT_BINARY_DIR}/IlmBase/Iex/$<CONFIGURATION>
${CMAKE_CURRENT_BINARY_DIR}/OpenEXR/IlmImf/$<CONFIGURATION>
COMMAND ${CMAKE_COMMAND} -E copy_directory
${CMAKE_CURRENT_BINARY_DIR}/IlmBase/Imath/$<CONFIGURATION>
${CMAKE_CURRENT_BINARY_DIR}/OpenEXR/IlmImf/$<CONFIGURATION>
)
** file nori-layers/ext/tbb/include/tbb/pipeline.h
Replace line 328:
template<typename T> struct tbb_trivially_copyable { enum { value = std::has_trivial_copy_constructor<T>::value }; };
by:
template<typename T> struct tbb_trivially_copyable { enum { value = std::is_trivially_copy_constructible<T>::value }; };
However none of the jupyter notebooks worked due to a problem with the version of prompt_toolkit. jupyter notebooks to replicate the results are provided. I could turn some of them into python scripts, but there were a lot of compatibility issues with matplotlib. Also don't forget to source setpath.sh to be able to import the compiled mitsuba in python.
MacOS Attempt: The paper provides the code and data to reproduce the paper results (C++ code and jupyter notebooks to reproduce the figures). Unfortunately, the mitsuba-layers and nori renderer fail to compile on linux and macOS. E.g.:
- mitsuba-layers (on macOS): issue with tbb
[ 1%] Built target mitsuba-layer-obj
[ 1%] Built target tbb_def_files
[ 1%] Linking CXX shared library libtbb.dylib
clang: error: no such file or directory: 'and'
clang: error: no such file or directory: 'data/mitsuba-layers/b1/ext_build/tbb/tbb.def'
- nori : Thread issue at cmake level.
